ENVO Stax Pro

ENVO Stax Pro

Enhanced Comfort Suspension
The Stax Pro comes equipped with a suspension mono-shock fork, absorbing bumps and vibrations for a smoother, more comfortable journey.

Secure and Adjustable Features
Enjoy a locking seatpost clamp and an adjustable handlebar for better security and a custom fit—tailored to match your riding style.

Impressive Range and Accessories
The dual battery option extends your ride up to 200 km, and all essential accessories come pre-assembled for immediate use.

Specifications:

• Frame: Hydro-formed Alloy 6061 TIG welded
• Fork: ZOOM 109D mono-shock fork, tapered from 1-1/8" to 1-1/2", with internal cable routing
• Battery: UL 2271 Certified 36V12.8Ah
• Motor: Brushless 36V 500W rear motor
• Brake Set: Shimano Hydraulic Disk brakes BR-MT200, with 180mm Rotor
• Charger: Charger 36V/2A
• Transmission: SHIMANO Altus SL-M315 - 8 Speed
• Tire: Kenda, 27.5x1.95, K1153
• Pedal: Alloy, 9/16” WELLGO
• Chain: TEC, C70
• Sensor: PAS/thumb throttle, speed sensor
• Display: LCD Color Display panel, with bluetooth connectivity
• Rear Carrier: Alloy carrier, black
• Fender: PVC Plastic fender

Stax Pro vs. Stax:

Both the Stax and Stax Pro are electric road bikes that are designed to look and feel like traditional road bikes. They both have the same lightweight aluminum frame, comfortable geometry, and powerful hub motor. They also both come with a 460Wh battery that provides up to 100 km of range.

Differences - the main differences between the Stax and Stax Pro are:

• Suspension: The Stax Pro comes with a suspension mono-shock fork, which can help to absorb bumps and vibrations from the road. The Stax does not have a suspension fork.
• Seatpost Clamp: The Stax Pro comes with a locking seatpost clamp as standard, while the Stax requires you to purchase a locking seatpost separately.
• Adjustable Handlebar: Stax Pro comes with adjustable handlebar allowing you to finetune the reach and stack.
• Tire Size: Stax Pro comes with 27.5'' hydbrid tires compared to 700C road tires for Stax.
• Battery: The Stax Pro allows you to use a dual battery option, which can extend the range of the bike to up to 200 km. The Stax does not have this option.
• Accessories: The Stax Pro comes with all the accessories assembled, including a rear rack, throttle, fenders, and kickstand. The Stax requires you to purchase these accessories separately.

Key Features

BATTERY PACK: The battery is removable and can reach a range of up to 100 km / 62 miles per charge on pedal assist level 1. The battery can be charged on or off the bike frame using the little portable CC-CV smart Li-Ion battery charger. The ENVO Battery contains a BMS that avoids battery from overcharging, overloading and other hazardous activities, thereby increasing both cyclic and calendar life of the battery. Battery cells have been selected for best operating in freezing temperatures

SUSPENSION FORK: Suspension mono-shock front fork with 25mm travel adds to high-speed stability and handling on trails and asphalt. It reduces the shocks to the frame and battery system and provides ultimate comfort.

LIGHT SPORTY FRAME: Stax features a solid, super lightweight, and stylish frame. This frame is made of 6061Aluminum Alloy which is treated with T6 heat treatment. ENVO uses atechnique called hydroforming to get the beautiful curve and ergonomicgeometry.

E-ASSIST SYSTEM: Stax is equipped with an advanced pedal assist sensor with optimized torque emulation software. The advanced torque emulating Pedal Assist Sensor (PAS) signals the controller to run the motor between 5 levels of pedal assist, providing a boost to your pedalling depending on the level of assistance you select while riding. Stax also supports an optional on-demand thumb throttle that gives you an extra boost which activates the motor proportionally to the twist regardless of pedalling to give you a fully electric ride in case you cannot pedal or need an instant acceleration or uphill push.

Fenders and Rack: Brave any weather with confidence thanks to the durable fenders that protect you from the elements, ensuring a comfortable ride even in the rain. Plus, the robust rear rack offers unparalleled utility, perfect for carrying groceries on your daily errands or securely attaching a child seat for joyful rides with your little one.

HYDRAULIC DISK BRAKE: Top of the line Shimano hydraulic disk brakes equipped with electric cut-off sensors provide more safety to the bike as well as the rider.

HEADLIGHT: The Stax is fitted with high efficiency and bright integrated LED 40 LUX headlight powered by the main battery and controlled by a keypad on the handlebar.

GEARED HUB MOTORS: ENVO Stax is equipped with a sealed, powerful, geared hub motor that offers 500W power and 60Nm torque. The bike is a street-legal bike with legalized speed, torque and power all over Canada and most parts of the US. Our motors are 50% lighter than all the rest powered geared hub motors in Canada, yet they deliver 50% more torque and 25% more battery efficiency. These ENVO motors are developed for over 20,000Km/ 12,400 miles maintenance-free ride.

TRANSMISSION SYSTEM: Well-engineered 8 speed 48T chain ring and 11-32 cassette transmission help you overcome up to 25% grade when climbing a hill on gear 1 or 40km/h speed on gear 8 with gentle pedaling.

Upgrade to the Stax Pro today for unbeatable comfort, convenience, and extra distance on every electrifying trip!
